T20-Digital Mixer

Product parameters

•・Developed based on Linux operating system, no fear of viruses, safer and more stable operation

  Upgraded version of 4-core CPU processor, 1G clock, 16 seconds to power on quickly, running faster

•・16 MIC/Line inputs, 1 x 6.5 stereo input, 1 x 3.5 stereo input, 1 x digital input: AES I/SOUND CARD, MP3

•・Input channel panning adjustment

•・Mic input channel parity stereo intermodulation

•・MIC input gain adjustment (digital gain).

•+48V phantom power (MIC channels can be turned on and off independently).

•・Built-in compressor, high and low pass, 5-band parametric equalization, time delay, channel acoustic and pan balance adjustment

•・Fast copy function of channel parameters

•・Input and output EQ ON/OFF

•・Multi-function knob

• ・ Each channel is equipped with multi-function menu, mute and monitor

•・THE CHANNELS ARE EQUIPPED WITH A STROKE 100MM ELECTRIC ACTUATOR, SIGNAL, PEAK LIGHT (17A-LPS ELECTRIC FADERS).

•・10 signal outputs (main output L, R, 4 AUX output, 4 group output).

•・AUX output (fader front/back).

•Output processing: high and low pass filtering, 15-31 band parametric equalization, compressor, delay, phase

•・Digital recording function

• User customizable layers, output mix editing function

•・Double-row 3-color 12-segment level indicator

•・Built-in sound card (MP3, PC direct music playback).

•・4 shortcut scene call modes, 100 scene storage, customizable scene names, seamless scene switching, no staccato.

•・Storage and retrieval of user parameters (can be managed on the PC side).

•・Built-in two independent DSP effects

•FX foot switch interface

•・AES digital signal input/output

•・Support RS232/485/TCP protocol central control

•・Multi-operating system control software (IOS, Android, WINDOWS).

•・ Support 100M wired network port adjustment (or external router wireless adjustment).

•・7 inch 1024*600 HD capacitive touch display

Machine size/weight

LENGTH, WIDTH AND HEIGHT: 497*515*215MM (length includes 6.35 input base, width includes side panels, height includes feet; Knob not included).

NET WEIGHT:11.69KG    GROSS WEIGHT:13.7KG

PACKING SIZE: 620*620*310MM

Applications: conference rooms, multi-function halls, small performances, small bands, government, schools, bars, wedding companies, rental companies, banquet halls, military, cultural auditoriums, cultural centers, exhibitions, etc
